Place of Origin | wuhan, China |
Brand Name | OEM |
Item
|
Technical Parameter Description
|
|
|
|
|||
Door Frame Shape
|
Flat frame type, encircle frame type, clamping type, plug-in type (customized according to customer requirements)
|
|
|
|
|||
Material
|
Electrogalvanized steel plate, 1.5mm for door frame, 1.0mm for door panel,1.2mm for inner reinforcing plate
|
|
|
|
|||
Filler
|
Flame retardant paper honeycomb
|
Fireproof aluminum honeycomb
|
Rock wool
|
Polyurethane foam
|
|||
Door Leaf Window
|
Square Glass
|
Oval glass
|
Square outside and round inside glass
|
Single, double galss
|
|||
Hardware Accessories
|
Locks: separate execution lock, compact execution lock, elbow press lock, escape lock, touch bead lock, etc.
|
|
|
|
|||
|
Hinge: detachable type, semi-hidden adjustment type, spring hydraulic type, hidden type, etc.
|
|
|
|
|||
|
Sealing device: door leaf self-adhesive type, door frame embedded type, door bottom automatic lifting type.
|
|
|
|
|||
Surface Treatment
|
Spraying (outdoor fluorocarbon powder, electrostatic powder), stoving varnish, paint-free (color can be customized according to
the customer requirements) |
|
|
|
|||
Wind Resistance Performance P3(KPa)
|
2.8 Air Pressure 100.8KPa
|
|
Airtightness q1=1.0 -q1=0.6
|
|
|||
|
|
|
q(m³/(m-h)) q2=2.1 -q1=1.5
|
|
|||
Door Leaf Weight m²/KG
|
Paper honeycomb
|
Aluminum honeycomb
|
Rock wool
|
Polyurethane
|
|||
|
21.5KG
|
22.3KG
|
24.5KG
|
26.0KG
|
Features:
1. High sealing performance: To ensure the cleanliness and stability of the internal environment of the cleanroom.
2. Smooth surface: Facilitates easy cleaning and reduces the accumulation of dirt and bacteria.
3. Anti-static material: Prevents the generation and accumulation of static electricity, reducing the impact on sensitive electronic components.
4. Durable construction: Made of high-quality materials to withstand frequent use and harsh conditions.
Applications:
1. Pharmaceutical industry: Maintaining a sterile environment for drug production.
2. Electronics manufacturing: Protecting sensitive electronic components from contamination.
3. Hospitals and laboratories: Ensuring the safety and purity of medical and research processes.
Advantages:
1. Improved product quality: Reduces the risk of contamination, leading to higher-quality end products.
2. Energy efficiency: Helps maintain a stable temperature and humidity, reducing energy consumption.
3. Enhanced safety: Prevents the entry of external pollutants and protects workers' health.
4. Long service life: Low maintenance requirements and reliable performance over time.
Packaging and Transportation:
1. The cleanroom doors are carefully wrapped with protective materials to prevent scratches and damage during transportation.
2. They are placed in sturdy crates or container
